Frameset

• Frame

  Timberjack Alloy V2

• Color

  Blue

• Suspension Fork

  RockShox 35 Gold RL, 130 mm, 44 mm offset

• Rear Shock

  N/A

Components

• Headset

  FSA Orbit 1.5E ACB

• Seatpost

  TranzX YSI05 RAD+, Shimano MT500 lever, 30 mm travel adj

• Stem

  Salsa Guide Trail

• Grips/Bar Tape

  Salsa File Tread

• Saddle

  WTB Volt 250 Steel

• Handlebar

  Race Face Chester 35

Drivetrain

• Front Derailleur

  N/A

• Rear Derailleur

  Shimano XT M8100 SGS

• Cassette

  Shimano SLX M7100-12, 10–51t, 12-speed

• Chain

  Shimano Deore M6100

• Crankset

  Shimano MT510, 30t

• Shifter

  Shimano SLX M7100 I-SPEC EV

• Brake Calipers

  Shimano M4120 four-piston

• Rotors

  Shimano RT10 Center Lock (180 mm front, 160 mm rear)

Wheels

• Front Wheel

  Shimano MT400-B 15 x 110 mm hub, WTB ST i30 32h 29" rim

• Rear Wheel

  Shimano MT410-B Micro Spline 12 x 148 mm hub, WTB ST i30 32h 29" rim

• Front Tire

  Maxxis Minion DHF front, 29 x 2.6", EXO, TR

• Rear Tire

  Maxxis Rekon rear, 29 x 2.6", EXO, TR

Weight

• Complete Bike

  31 lbs 13 oz for Medium

6061-T6 Aluminum Tubing

Timberjack is built from our proprietary, top-shelf 6061-T6 aluminum tubing, which is double- and triple-butted in the main triangle for a light, responsive, and durable frame with great trail feel.

Timberjack Geometry

Our second-generation Timberjack geometry is longer, lower, and slacker for aggressive riding. A 66-degree head tube and long wheelbase make for a stable ride, while a long reach and steep (75-degree) seat tube balance weight distribution for efficient pedaling. Short chainstays (adjustable from 420–437 mm) keep the rear end nimble for responsive handling.

140 mm Suspension Fork

Soak up the harshness of gnarly roots, rock gardens, drops, or whatever’s in your path with 140 mm of suspension travel up front. Timberjack accommodates forks with up to 150 mm of travel.

Adjustable TranzX dropper post

Get your saddle out of the way for steep descents and technical sections with the included dropper post. 30 mm of tool-free travel adjustment lets you dial in the right travel for your fit and riding style.

Alternator 2.0 Dropouts

Our adjustable Alternator dropout system lets you run Timberjack geared or single-speed and accommodates multiple hub standards. Built-in adjustability gives you 17 mm of wheelbase travel so you can dial in your preferred ride characteristics.

Bottle & Accessory Mounts

SM–XL frames have two bottle mounts—including a Three-Pack mount on the downtube—in the main triangle (XS frames have only the Three-Pack mount on the downtube). All sizes feature an accessory mount on the underside of the down tube, plus top tube mounts for our EXP Series Direct Mount Top Tube Bag means room for more ride essentials. Rear rack mounts open up possibilities for larger loads.

Full-Length Internal Routing

Full-length internal routing for brake lines and shift cable housing means more reliable performance in sloppy conditions, simplified maintenance, and a better fit for frame bags.
